ARPool in London UK!

Jeremy Clarkson, Me, Stephen Fry, Salar on the set of Gadget Man

Just got back from taking ARPool to London England (wow what a trip!) I’ll write a blog about my trip later but right now I just want to focus on ARPool.

On Thursday Chris and Alex from North One Television were about an hour late picking us up at our hotel so we were starting to set up behind schedule. I’m pretty thankful that the schedule was changed so that filming was late afternoon on Friday rather than morning or we would have been very pressed for time. I had to help build the Truss – so much for this being a show up and plug in a computer gig, anyways it wasn’t too big a deal and at least I didn’t have to carry and assemble a pool table like past events. We got the structure up and mounted the camera and projector (I am a wizard with zip-ties!) and fired up the calibration.

Things were not as smooth as I had expected – the table calibration step, the final step that creates the transformation matrices was giving us grief - the final image after the transformation was either rotated 90 degrees or had some really strange jagged distortion. I thought I had fixed this step but it needs more work – I expect the problem is in the line intersection code possible a bad solution or an overflow problem. It is really weird because you can perform this step multiple times without altering the code and it can give wildly different results. I think that drawing more intermediate images will fix this problem especially during the line intersection process.

* edit * The week after we got back I added more intermediate debugging visuals which are nice to confirm the calibration is doing what we expect but didn’t solve the issue. Still can’t believe this but our source of grief was from Qt being unable to display images with an odd number of rows or columns. That alone makes sense but what still confounds me is how this hadn’t come before…

Anyways thanks to the randomness of the table calibration procedure it eventually worked for us and we moved on to finish the calibration. We skipped ball training and simply ran the system, surprisingly the classifier was still able to get the cue ball!

Stephen Fry playing ARPool - also I swear I am not photo-shopped into this photo its just a weird affect from the light behind me!

The filming process was very interesting, there were tons of crew members and I could never really figure out who was in charge with the exception of the director. I got to briefly explain to Stephen Fry and Jeremy Clarkson how the system worked and how to use it before they played a game on film. Stephen Fry got to use ARPool while Jeremy was on his own. The shoot went pretty well but after the first shot Stephen Fry sort of forgot how to use it and didn’t have the cue close enough to the cue ball for it to detect the shot. They also both kept bumping into the truss which of course can throw off the whole calibration -wince! After their game we filmed a few sequences of Stephen using ARPool which were set up and I was there to guide him through making the shot. ARPool isn’t quite a hands off demo at this point! We got a few more shots after the celebrities left and everyone was pretty happy with how it went and I am sure that it will look great!

read more

ARPool London Preparation

I’ve spent a great deal of time this past month getting ARPool ready for our trip to London UK to be on Stephen Fry Gadget Man. So much has happened it is going to be tough for me to remember it all!

It begins by testing all the code I wrote after OCE which actually essentially worked on the first try a minor miracle! After confirming that ARPool 2.0 ran we spent the next week improving the calibration process. I added much better debugging visuals and several new functions including a really handy calibration test function which tests the mapping from image coordinates to projector coordinates by drawing test points on the table so you can confirm the calibration accuracy.

With calibration looking pretty good I moved onto the ARRecogntion Class. This class is the work horse of ARPool all the vision algorithms are in here. I started by cleaning the code and adding documentation – you heard right in ~4 years of the project no one has documented it… I made a nice comment block above each function clearly explaining its purpose, its inputs (in detail such as if the image is rectified or not etc.), outputs. There is also a debugging tips section.

I made many small improvements to ARRecognition and a few major ones – notably I re-did the motionDetection algorithm which detects when the shot is finished restarting the process. I also worked on the detectShot algorithm to fix a bug where another ball next to the cue ball would cause a shot to not be detected. The first major change was in the detectBalls function where I added code for detecting balls whose blobs are joined after background subtraction. The final algorithm here is quite slick, if the blob is bigger than a single ball a matchTemplate is ran to find the 2,3,4 etc. best balls in the image. A max search is performed on the output of matchTemplate and the location is recorded and then a black circle is drawn centered at the point before running another max search. This ensures the balls that are found are not overlapping at all. This change made a big difference in the performance of the system – especially since we could now be more relaxed on the background subtraction threshold since ball blobs joining is no longer an issue. I also added some code for the special case of finding the balls when they are set up for the break shot.

That explanation was kind of brutal and if you’re actually reading this your probably like code so here is the source!

/   segmentBallClusters
/   Input: blobs image and the contour to be segmented
/          numBalls - the number of balls the contour should be segmented into
/          centers - a vector of ball centers not an input but an output via reference
/   Return: the ball centers in the vector by reference
/   Purpose: Segment a blob into a number of balls, gets called by detectBallCenters
/            when a blob is the the area of nultiple balls, e.g. two balls are touching
/   Debugging Tips: Check the blobs image saved by detectBallCenters
/                   watch what the erode is doing
/                   imshow the "results" image
void ARRecognition::segmentBallClusters(cv::Mat &blobs, std::vector<cv::Point> &contour, int numBalls, std::vector<cv::Point2f> &centers)
    // draw the blob onto the blobs image
    std::vector<std::vector<cv::Point> > contours;
    cv::drawContours(blobs, contours, -1, cv::Scalar(255,255,255), CV_FILLED);

    // get an ROI of the blob we need to segment
    cv::Rect rect = cv::boundingRect(contour);
    cv::Mat roi = blobs(rect).clone();

    // template for the ball
    cv::Mat templ = cv::Mat::zeros(m_ball_radius*2,m_ball_radius*2,CV_8U);
    cv::circle(templ, cv::Point(m_ball_radius, m_ball_radius), m_ball_radius, cv::Scalar(255,255,255), CV_FILLED);

    cv::Mat result;

    cv::Point offset(rect.x, rect.y);

    if(numBalls != 15)
for(int i = 0; i < numBalls; i++)
    // find the maximum
    double minVal;
    double maxVal;
    cv::Point minLoc;
    cv::Point maxLoc;

    // add ball center at max loc
    cv::Point center(maxLoc.x + offset.x + m_ball_radius, maxLoc.y + offset.y + m_ball_radius);

    // remove this max by drawing a black circle

    // numBalls == 15 -- Special case for the "break"
cv::findContours(roi.clone(), contours, CV_RETR_EXTERNAL, CV_CHAIN_APPROX_NONE);

std::vector<cv::Point> polygon;
double precision = 1.0;

while(polygon.size() != 3)
    //std::cout << "precision" << precision << " num polygon vertices" << polygon.size() << std::endl;
    cv::approxPolyDP(contours[0], polygon,precision,true);
    precision += 0.1;

// add offset to polygon points
for(int k = 0; k < 3; k++)
    polygon[k] += offset;


// interpolate ball centers
centers.push_back(polygon[0] - 0.25*(polygon[0] - polygon[1]) - 0.25*(polygon[0] - polygon[2]));

centers.push_back(polygon[0] + 0.7 * (polygon[1] - polygon[0]));
centers.push_back(polygon[0] + 0.5 * (polygon[1] - polygon[0]));
centers.push_back(polygon[0] + 0.3 * (polygon[1] - polygon[0]));

centers.push_back(polygon[1] - 0.25*(polygon[1] - polygon[2]) - 0.25*(polygon[1] - polygon[0]));

centers.push_back(polygon[1] + 0.7 * (polygon[2] - polygon[1]));
centers.push_back(polygon[1] + 0.5 * (polygon[2] - polygon[1]));
centers.push_back(polygon[1] + 0.3 * (polygon[2] - polygon[1]));

centers.push_back(polygon[2] - 0.25*(polygon[2] - polygon[1]) - 0.25*(polygon[2] - polygon[0]));

centers.push_back(polygon[2] + 0.7 * (polygon[0] - polygon[2]));
centers.push_back(polygon[2] + 0.5 * (polygon[0] - polygon[2]));
centers.push_back(polygon[2] + 0.3 * (polygon[0] - polygon[2]));


The biggest change I made was to re-do the ball identification system. The current one was not working great and was very messy code wise which I didn’t like. I wanted to make it cleaner, easier to maintain and I wanted it to use the OpenCV machine learning module. I gathered a bunch of training and test data and started playing around with the data. I found great success with cvBoost classifiers. The new system is a bit different as it employs different classifiers for different purposes. First a classifier picks the cue ball from all the other balls (1 vs all) and another does the same for the 8 ball. Another classifier classifies the remaining balls as either stripes or solids before finally 2 separate classifiers assign actual numbers. This is great because each level is a fail safe. Our primary concern is finding the cue ball properly, next is the 8 ball. The actual number is the least important but it is good to know if the ball is a stripe or a solid.

With ARRecognition in the best shape its ever been in I started investigating the graphics code and why our drawImage function was not working properly any more.  I wasted the whole first afternoon just trying to find a solution worked out for me online – it was one of those things where I just didn’t feel like diving in and as a result I got no where. The next day though I had motivation again – I started the graphics code from scratch adding back one function at a time. This turned out to be a really good thing to do because now I understand the graphics code. I was also able to consolidate all the opengl code from about 4 different .cpp files into a single file, now all the drawing code was in one place brilliant! I added the same documentation as I had for ARRecognition – man this project is starting to look very nice!

All of this work has been very satisfying for me but it makes me a bit sad that no one truly appreciates all the vast improvements I have made except for me. The system looks the same when it is running but the code behind is so much more reliable and easy to work with. I’m sure it will pay off in London!

read more

The Arch Linux Plunge

I finally took the plunge. It’s Thanksgiving in Canada and I am taking a nice relaxing break from work by installing Arch Linux for the first time. I suppose its not what most people do for a break from work but hey I am a huge nerd what can I say. I’d been interested in Arch Linux for quite a while and this weekend was just what I needed to get started.

The install process was actually fairly smooth, there were a few bumps here and there but as people always say the Arch forums are fantastic and they helped me more than a few times. So I was working through the install, which is all terminal in case you haven’t done it, while simultaneously installing a new version of Android on my phone when I realise that I needed to leave the house in 15 minutes to get to Thanksgiving dinner on time. I pause, I really want to finish this install but I don’t know how much is left and I don’t want to have to start over. That’s when I thought about exactly what I had done and how I was doing it and realised that I could simply resume at this exact point later but booting from the live usb and mounting the install partition under /mnt and then running chroot again. It was a cool moment and a bunch of stuff just kind of clicked in my brain – Linux level up!

I returned the next day and finished the install fairly quickly (and by finish I mean I can boot into my Arch install using GRUB after it boots it is still just a terminal). I continued on and installed X11 and company. For my window manager I wanted to go with openbox because it is super fast and lightweight kind of how I envision my laptop being. It was neat to see how all of these separate programs work together. I added a file explorer and graphical text editor.

I want to stop here and just briefly mention that throughout this whole install I’ve been slowly falling in love with Arch’s package manager pacman. It is truly amazing! That’s pretty much all I got there.

I was surprised at how quickly I was able to get my system up and running – what was weird was that it was surprisingly easy to get the various tools and stuff that I wanted but what was really hard and still unfinished is getting all the various widgets we take for granted like the wifi menu and battery indicator in the panel etc. Basically my system works, has all the tools I want, is blazing fast but looks like shit lol. Project for another day!

* edit * discovered ArchBang, it is basically Arch except with a few more common things installed like the network manager and battery widget. They also have already put some time into configuring openbox so it actually looks good. I’m glad I went through the Arch config once but in the future I may just cheat and start with ArchBang!
